6-32 UNC DIN HSSE 3FLT UNI SPPT 2B Black Oxide PRO-961SP
- GLD# GREEN-128320
- MFG# C96106
Min. Order Qty 1
Description
Cleveland taraud à pointe spiral, haute performance universel, gamme : pro-961sp, standard de filetage rectifié/unc, fil #6-32, intermédiaire, 3 goujures, hss-e, oxyde de vapeur, classe dajustement : 2b, coupe à droite, 0.4331 po longueur de filetage, 2.2047 po longueur totale, 0.141 po queue diamètre, 0.19 pouces file dattente longueur, acier, acier inoxydable, matériaux non ferreux et durs APPLICATION de matériaux
Specifications
| Application | For through hole applications |
|---|---|
| Chamfer Type | Plug |
| Cutting Direction | Right Hand |
| Finish/Coating | Steam Oxide |
| Material | HSS-E |
| Number of Flutes | 3 |
| Overall Length | 2.2047 in |
| Series | PRO-961SP |
| Shank Diameter | 0.141 in |
| Thread Length | 0.4331 in |
| Thread Size | #6-32 |
| Thread Standard | Ground/UNC |
| Type | High Performance Universal |
| Shank Length | 0.19 in |
| Class of Fit | 2B |
| Through Coolant (Yes/No) | No |
| Adjustable Die (Yes/No) | No |
| Material Application | Hard Materials, Non-Ferrous, Stainless Steel, Steel |
| UNSPSC | 23241615 |
