Brand
Dixon®
1 S Boss Clamp
- GLD# 9923388
- MFG# BU14
Min. Order Qty 1
Description
Dixon® 4-Bolt Clamp, Series: Boss™, 1 in Inside Dia, 1-34/64 to 1-46/64 in Outside Dia, 2-7/8 in Length, 3-1/8 in Width, 9/16 in Hex Bolt, 21 ft lb, Iron Band, Zinc Plated, Domestic
Specifications
| UNSPSC | 31162906 |
|---|---|
| Domestic/Import | Domestic |
| Finish | Zinc Plated |
| Inside Diameter | 1 in |
| Series | Boss™ |
| Width | 3-1/8 in |
| Length | 2-7/8 in |
| Torque Rating | 21 ft-lb |
| Outside Diameter | 1-34/64 to 1-46/64 in |
| Bolt Size | 9/16 in Hex |
| Band Material | Iron |
Features
- Recommended for steam service up to 450 deg F
- Replacement nuts and bolts are available
- Two gripping fingers and two clamps sections
- The bolts used in the boss interlocking clamps are not standard bolts
- They vary from standard bolts in their lengths, diameter, overall thread lengths and materials hardness
- These bolts can be retorqued, but it is not recommended to reuse the bolts or clamps, as they are designed for a single bend only
- Torque values for clamps are based on dry bolts
- The use of lubricant on bolts will adversely effect clamps performance
- Do not lubricate nuts and bolts
- Bolts in boss clamps are designed to bend as they are tightened and this allows the clamps to conform to the hose outside diameter
