3" Part F Adptr St. Steel
- GLD# 9847460
- MFG# 300-F-SS
Min. Order Qty 1
Description
Dixon Adaptateur came et rainure , type f, gamme : boss-lock, adaptateur, 3 po nominal, adaptateur mâle x mnpt, longueur 4-15/32 po, 125 lb/po-ca, acier inoxydable 316
Specifications
| UNSPSC | 40141734 |
|---|---|
| Application | Designed for use with liquids |
| End Style | Male Adapter x MNPT |
| Fitting/Connector Type | Adapter |
| Material | 316 Stainless Steel |
| Nominal Size | 3 in |
| Pressure Rating | 125 psi |
| Series | Boss-Lock™ |
| Type | Type F |
| Length | 4-15/32 in |
Features
- Under no circumstances should cam and groove couplings be used for compressed air or steam service!
- Pressure rating is based on the seal of the mating part
- Pressure rating recommendations are based on the use of mating Dixon fittings at ambient temperature 70 deg F with a standard seal installed
- 125 psi at ambient temperature 70 deg F pressure
- Warning: this product contains a chemical known to the state of California to cause birth defects or other reproductive harm
- Do not use in connection with drinking water
- Wash hands after handling
