9561 1/2 TON 15 FT ELEC HOIST
- GLD# MIL-112068
- MFG# 9561
- UPC 045242069057
Qté min. de commande 1
Description
Milwaukee palan électrique à chaîne, monophasé léger, 1/2 tonne, hauteur de levage 15 pi, 16 pi/min vitesse de levage, 24 vca commande de poste à bouton-poussoir, frein à disque magnétique, 0,5 hp, 115 à 230 vca, 7,6 a, 3,8 a, rouge
Spécifications
| Couleur | Red |
|---|---|
| UNSPSC | 24101602 |
| Amperage Rating | 3.8/7.6 A |
| Brake Type | Magnetic Disc |
| Control Type | 24 VAC Pushbutton Station |
| Lift Speed | 16 fpm |
| Lifting Height | 15 ft |
| Load Capacity | 0.5 ton |
| Power Rating | 1/2 hp |
| Type | 1-Phase Lightweight |
| Voltage Rating | 115 to 230 VAC |
| Application | For general industrial use for lifting and transporting freely suspended material loads within its rated capacity |
Caractéristiques
- Built-in, multiple-disc, magnetic brake provides positive load holding and spotting
- Adjustable upper and lower limit switches for maximum flexibility in regulating load travel
- Overload limiting clutch guards against lifting damaging overloads while operating hoist
- Duty service classification H-3 on time up to 25% of work period, 3-phase on time up to 33% of work period
- Latch type ridged top hook on all models
- Aluminum housing, corrosion-resistant, reduced weight allows greater portability
- Single chained reeving
