0610 1/2''-13 FILIERE ROND CARB STEEL 1"OD
- GLD# 1000014596
- MFG# C65470
Qté min. de commande 1
Description
Matrice réglable cle-line, ronde, gamme : 610, système de mesure : impérial, filetage 1/2-13, filetage unc, épaisseur 3/8 po, 1 po dia ext filière, acier au carbone, brillant
Spécifications
| Application | General Purpose Applications |
|---|---|
| Material | Carbon Steel |
| Measurement System | Imperial |
| Series | 610 |
| Thread Size | 1/2-13 |
| Type | Round |
| Die Outside Diameter | 1 in |
| Finish | Bright |
| Thickness | 3/8 in |
| Thread Type | UNC |
| Through Coolant (Yes/No) | Non |
| Adjustable Die (Yes/No) | Non |
| UNSPSC | 27112833 |
Caractéristiques
- Short chamfer on both sides of die to extend tool life
- Adjustable for wear and size
- Cut external threads when held in a die stock
- Produce UN thread form
- Can be used for close to shoulder work
Guides & Manuels
Cle_Line_C17760_Catalog.pdf
Télécharger
