0610 9/16-12FILIERE ROND CARB STEEL 1.5"OD
- GLD# 4190438008920381039
- MFG# C65239
- UPC 697334652397
Qté min. de commande 1
Description
Cle-Line Matrice réglable , ronde, gamme : 610, système de mesure : impérial, filetage 9/16-12, filetage unc, 1/2 po dépaisseur, matrice dia ext 1-1/2 po, acier au carbone, brillant
Spécifications
| Application | General Purpose Applications |
|---|---|
| Material | Carbon Steel |
| Measurement System | Imperial |
| Series | 610 |
| Thread Size | 9/16-12 |
| Type | Round |
| Die Outside Diameter | 1-1/2 in |
| Finish | Bright |
| Thickness | 1/2 in |
| Thread Type | UNC |
| Through Coolant (Yes/No) | Non |
| Adjustable Die (Yes/No) | Non |
| UNSPSC | 27112833 |
Caractéristiques
- Short chamfer on both sides of die to extend tool life
- Adjustable for wear and size
- Cut external threads when held in a die stock
- Produce UN thread form
- Can be used for close to shoulder work
