FILIERE RONDE M8X1.25 HSS 1"OD
- GLD# 4190438008920381116
- MFG# C65813
- UPC 697334658139
Qté min. de commande 1
Description
Cle-Line Matrice réglable , ronde, gamme : 0710m, système de mesure : métrique, filetage m8x1,25, filetage grossier, épaisseur 9,52 mm, matrice dia ext 25,4 mm, hss, brillant
Spécifications
| Application | General Purpose Applications |
|---|---|
| Material | HSS |
| Measurement System | Metric |
| Series | 0710M |
| Thread Size | M8x1.25 |
| Type | Round |
| Die Outside Diameter | 25.4 mm |
| Finish | Bright |
| Thickness | 9.52 mm |
| Thread Type | Coarse |
| Through Coolant (Yes/No) | Non |
| Adjustable Die (Yes/No) | Non |
| UNSPSC | 27112833 |
Caractéristiques
- Short chamfer on both sides of die to extend tool life
- Adjustable for wear and size
- Cut external threads when held in a die stock
- Produce UN thread form
- Can be used for close to shoulder work
Guides & Manuels
Cle_Line_C17760_Catalog.pdf
Télécharger
