1/2 610 60DG CTR RMR
- GLD# GREEN-120279
- MFG# C46210
Temps de livraison estimé
24 à 48h
Qté min. de commande 1
Description
Cleveland alésoir/fraise central, à peu près simple, jeu : 610, corps de 1/2 po diamètre, 2 po longueur totale, file droite, 3/8 po file dattente de diamètre, 4 goujures, coupe à droite, 60 deg angle inclus, 30 deg angle daxe, hss, oxyde de vapeur
Spécifications
| UNSPSC | 27112812 |
|---|---|
| Application | Used to countersink flat head screws and rivets |
| Cutting Direction | Right Hand |
| Finish | Steam Oxide |
| Material | HSS |
| Overall Length | 2 in |
| Series | 610 |
| Shank Type | Straight |
| Type | Single End |
| Number of Flutes | 4 |
| Through Coolant (Yes/No) | Non |
| Body Diameter | 1/2 in |
| Centerline Angle | 30 deg |
| Included Angle | 60 deg |
| Shank Diameter | 3/8 in |
Caractéristiques
- Used to countersink flat head screws and rivets
- Use single flute countersinks for smaller holes, multi-flute tools countersink much larger holes
- Run countersinks at 50 to 66% of recommended drill speeds
- The pre drilled hole for countersinking should not be less than 10% of the countersink diameter
