Single Fixture - J Box, 120/240VAC, Red
- GLD# 4281343206350606000
- MFG# RTO0R07005
- UPC 5056020916666
Qté min. de commande 1
Description
Feu de signalisation visuel durosite, signalisation, 120 à 240 vca, 8 w de puissance, lampe led, rouge, durée de vie moyenne de 5 ans, spécifications respectées : ul 1598, csa c22.2 citron vert no. 250, montage au plafond, nema 4x, -40 à 55 deg c, matière aluminium boîtier, 7.6 pouces x 5.25 pouces x 5.75 po dimensions d
Spécifications
| UNSPSC | 39111544 |
|---|---|
| Couleur | Red |
| Application | For both indoor and outdoor call boxes and emergency telephone locations or for safety showers or eye wash stations and visual signal lights applications |
| Dimensions | 7.6 in L x 5.25 in W x 5.75 in D |
| NEMA Rating | NEMA 4X |
| Temperature Rating | -40 to 55 deg C |
| Voltage Rating | 120 to 240 VAC |
| Average Life | 5 years |
| Lamp Type | LED |
| Wattage | 8 W |
| Type | Signaling |
| Mounting Type | Ceiling |
| Specifications Met | UL 1598, CSA C22.2 File No. 250 |
| Housing Material | Aluminum |
Caractéristiques
- Low power consumption
- Instant on/off response
- Weather/corrosion-resistant lamp assembly and housing
- Resistant to shock and vibration
- Precision patented optics ensure maximum safety with minimal ground scatter for community-friendly illumination
